Description
Product Details
Amperage Rating:
15 A
Connection:
Screw
Type:
Decorator, Straight Blade, Tamper Resistant
Number of Poles:
2
Material:
Thermoplastic/PVC Top and Bottom Housing
Number Of Wires:
3
Nema Rating:
NEMA 5-15R
Wire Size:
14 – 10 AWG
Voltage Rating:
125 VAC
Standards:
cULus Listed to UL 498, File No E15058, NOM Certified
Dielectric Strength:
2000 V
Temperature Rating:
-20 TO 60 deg C
Special Features:
Residential Grade, Side and Push Wire
Features
- Longer, wider strap provides 40 percent more contact area to wall board, virtually eliminates floating installations
- Patented built-in wire stripper for NO 14 and NO 12 wire to speed installation
- Patented built-in wire looper for pre-looping
- Tri-combo screws accept slotted, Philips and Robertson-head tools for installation flexibility
- Terminal screws backed out – ready for wiring
- Side wire terminals accept up to NO 10 solid or stranded wire
- Push-in terminals accept NO 14 solid wire for quick installation
- High impact-resistant thermoplastic face and back body eliminates breakage
- Double wipe ground contacts ensure long-term ground retention
- Easy access split circuit break-off tab
